graph.h File Reference

Graph. More...

#include "vertegs/vertex.h"

Include dependency graph for graph.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Data Structures
struct	VxGraphEmpty
	Vtable for message construction. More...

Macros
#define	VX_TYPEOF(var)   __typeof__(var)
	Get the type of a variable.
#define	VX_GRAPH(name, deg, type)
	Define the graph.
#define	vx_graph_2vx(graph)    (0 ? (struct Vertegs*)(graph)->vx_graph_nbor : (struct Vertegs*)(graph))
	Cast to generic vertex from a graph node.
#define	vx_graph_4vx(v, graph)
	Cast from a generic vertex to a graph node.
#define	vx_graphp_2vxp(graphp)    (0 ? (*(graphp))->vx_graph_nbor : (struct Vertegs**)(graphp))
	Cast to generic vertex double pointer from a graph node double pointer.
#define	vx_graph_datap(graph)   (&(graph)->vx_graph_data)
	Get a pointer to the data member of a graph node.
#define	vx_graph_foredge(type, i, graphp, edge)    for (type** i = graphp; *i; i = (type**)&(*i)->vx_graph_nbor[edge])
	Traverse a graph.

Functions
static const struct VxGraphEmpty *	vx_graph_empty (void)
	Return an empty graph.

Variables
static const struct VxGraphEmpty *	VX_GRAPH_EMPTY
	Empty graph - null pointer.

Detailed Description

Graph.

Macro Definition Documentation

VX_GRAPH

#define VX_GRAPH	(		name,
			deg,
			type
	)

Value:

        name                                                                   \
        {                                                                      \
                struct Vertegs* vx_graph_nbor[deg];                            \
                type vx_graph_data;                                            \
        }

Define the graph.

Parameters

[in]	name	The name of the type used for the graph.
[in]	deg	The degree of vertices - the number of neighbours.
[in]	type	The type of the data held by name.

This macro will define a compound type (must be struct or union) name, a type for a graph entry that holds the data of the type type.

vx_graph_2vx

#define vx_graph_2vx

(

graph

)

(0 ? (struct Vertegs*)(graph)->vx_graph_nbor : (struct Vertegs*)(graph))

Cast to generic vertex from a graph node.

Parameters

[in]

graph

The graph node.

Returns

The vertex.

vx_graph_4vx

#define vx_graph_4vx	(		v,
			graph
	)

Value:

        (0 ? (VX_TYPEOF(graph))((graph)->vx_graph_nbor[0] = (v)->nbor[0])      \
           : ((VX_TYPEOF(graph))(v)))

Cast from a generic vertex to a graph node.

Parameters

[in]	v	The vertex.
[in]	graph	A variable of the same type as the graph node.

Returns

The graph node.

vx_graph_datap

#define vx_graph_datap

(

graph

)

(&(graph)->vx_graph_data)

Get a pointer to the data member of a graph node.

Parameters

[in]

graph

The graph node.

Returns

The pointer to the data.

vx_graph_foredge

#define vx_graph_foredge	(		type,
			i,
			graphp,
			edge
	)		for (type** i = graphp; *i; i = (type**)&(*i)->vx_graph_nbor[edge])

Traverse a graph.

Traverse the graph of type type referenced by graphp along the edges of index edge, assigning every node in turn to i.

vx_graphp_2vxp

#define vx_graphp_2vxp

(

graphp

)

(0 ? (*(graphp))->vx_graph_nbor : (struct Vertegs**)(graphp))

Cast to generic vertex double pointer from a graph node double pointer.

Parameters

[in]

graphp

The graph node double pointer.

Returns

The vertex double pointer.

VX_TYPEOF

#define VX_TYPEOF

(

var

)

__typeof__(var)

Get the type of a variable.

Note

For strict ansi build this always returns a void pointer.

Function Documentation

vx_graph_empty()

static inline const struct VxGraphEmpty * vx_graph_empty ( void  )

inlinestatic

Return an empty graph.

Returns

The empty graph.
